KJG Hollow Paddle Dryer

KJG Hollow Paddle Blade Dryer is a solution for factories seeking efficient processing of paste, granular, powdery, and slurry materials. Designed for diverse unit operations like drying, cooling, heating, sterilization, reaction, and low-temperature combustion, this dryer boasts wedge-shaped stirring heat transfer blades with exceptional heat transfer efficiency and self-cleaning properties. The densely arranged hollow blades on the shaft enable a large heat transfer area per unit volume, accommodating heat mediums ranging from -40°C to 320°C, including water, hot water, and thermal oil. With indirect conduction heating, minimal heat loss, and a cleaning function on the blade surface, it ensures energy utilization and reduced environmental impact. Noteworthy features such as low energy consumption, cost-effectiveness, compatibility with various materials and heat media, low pollution, minimal maintenance, and stable operation make the KJG Hollow Paddle Dryer a reliable choice for industries requiring high-performance drying solutions.

Contact Us
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
  • KJG Hollow Paddle Dryer
PREV：No previous article
NEXT：No next article

Model/item KJG-3 KJG-9 KJG-13 KJG-18 KJG-29 KJG-41 KJG-52 KJG-68 KJG-81 KJG-95 KJG-110
Heat transfer area m2 3 9 13 18 29 41 52 68 81 95 110
Effective volume m3 0.06 0.32 0.59 1.09 1.85 2.8 3.96 5.21 6.43 8.07 9.46
Speed range r.m.p 15-30 10-25 10-25 10-20 10-20 10-20 10-20 10-20 5-15 5-15 5-10
Power kw 2.2 4 5.5 7.5 11 15 30 45 55 75 95
The body width is A mm 306 584 762 940 1118 1296 1474 1652 1828 2032 2210
Overall width B mm 736 841 1066 1320 1474 1676 1854 2134 1186 2438 2668
The body length is C mm 1956 2820 3048 3328 4114 4724 5258 5824 6020 6124 6122
The overall length is D mm 2972 4876 5486 5918 6808 7570 8306 9296 9678 9704 9880
Inlet and outfeed distance E mm 1752 2540 2768 3048 3810 4220 4954 5384 5562 5664 5664
Center height F mm 380 380 534 610 762 915 1066 1220 1220 1220 1220
The overall height is H mm 762 838 1092 1270 1524 1778 2032 2362 2464 2566 2668
Steam inlet N (inch) 45355 45355 1 1 1 1 11/2 11/2 11/2 11/2 2
Water outlet O (inch) 45355 45355 1 1 1 1 11/2 11/2 11/2 11/2 2
